All in One Solar LED Street Light LED Solar Wall Light Garden Street Lamp Bright Outdoor
The 9th-generation all-in-one solar street lights, featuring the 3545 G9, 3965 G9, and 3980 G9 series, are engineered to revolutionize outdoor lighting. Blending high-performance solar technology, long-lasting energy storage, and intelligent operation, they cater to diverse lighting demands while prioritizing sustainability. Here’s a closer look at each series’ unique strengths.
1. 3545 G9 Series: Compact Efficiency for Daily Lighting
1.1 Core Specifications
Power: 20W, balancing brightness and energy conservation for small-to-medium outdoor zones.
Solar Solution: 5V/45W monocrystalline solar panel (677×347×3MM) ensures efficient sunlight conversion, even in moderate sunlight.
Energy Storage: 3.2V/45Ah LiFePO4 battery (144Wh) offers stable power supply with excellent cycle life.
Lighting Quality: 60pcs 5050SMD LEDs deliver 180LM/W efficacy, Ra≥70 color rendering, and 3000K–6500K color temperature options. A 90X150° beam angle ensures uniform coverage.
Dimensions: 681×351×124MM, designed for space-saving installation.
1.2 Smart Performance
Charging & Lighting: 6–9 hours of charging supports 12 hours of nightly lighting, plus 2–3 rainy days of backup.
Motion-Aware Dimming: Triggers 100% brightness (20W) when detecting humans within 120°, and drops to 20% (4W) after 15 seconds of inactivity.
Durability: IK08 impact resistance and IP65 waterproof rating enable operation in -10℃–40℃ environments.
Longevity: LEDs (54,000+ hours), battery (2,500+ cycles), and solar panel (20–25 years) guarantee long-term reliability.
User-Friendly Add-Ons: Remote control for easy settings and 180° rotatable bracket for flexible lighting direction.
1.3 Ideal Scenarios
Rural roads, residential communities, small parks, and scenic spot pathways—perfect for areas needing consistent, low-maintenance lighting.
2. 3965 G9 Series: Enhanced Power for Busy Areas
2.1 Key Specifications
Power: 25W, providing stronger illumination for high-traffic outdoor spaces.
Solar Panel: 5V/68W monocrystalline panel (797×387×3MM) boosts energy capture for extended use.
Battery Capacity: 3.2V/60Ah LiFePO4 battery (192Wh) stores more energy for demanding lighting needs.
Lighting Output: 90pcs 5050SMD LEDs produce 4,500LM (180LM/W efficacy) with Ra≥70, ensuring clear visibility.
Size: 801×391×124MM, sturdy yet easy to install.
2.2 Advanced Functions
Energy & Dimming: Matches the 3545 G9’s charging/lighting duration; motion sensor adjusts brightness from 25W to 5W (20%) after 15 seconds.
Toughness: Same IK08/IP65 protection and long component lifespan as the 3545 G9.
Installation Flexibility: Supports pole, roof, or wall mounting, plus a customizable radar sensor for tailored detection.
Convenience: Remote control simplifies operation, ideal for areas requiring quick setting adjustments.
2.3 Target Applications
Municipal roads, outdoor basketball courts, highway service areas, and medium-sized scenic spots—built for busy zones with higher lighting demands.
3. 3980 G9 Series: Maximum Coverage for Large Spaces
3.1 High-Capacity Specifications
Power: 30W, delivering intense brightness for wide outdoor areas.
Solar Panel: 5V/80W monocrystalline panel (957×387×3MM) maximizes sunlight absorption for heavy-duty use.
Battery: 3.2V/75Ah LiFePO4 battery (240Wh) ensures prolonged power supply for large-scale lighting.
LED Configuration: 120pcs 5050SMD LEDs maintain 180LM/W efficacy and Ra≥70, covering extensive areas.
Installation Details: 15–20M mounting distance, 5–7M height, and 961×391×124MM size—optimized for large-span lighting.
3.2 Powerful Performance
Charging & Lighting: 6–9 hours of charging supports 12 hours of nightly use and 2–3 rainy days of backup.
Motion Dimming: Switches to 30W (100%) when detecting humans, and reduces to 6W (20%) after 15 seconds of no activity.
Durability: IK08 impact resistance, IP65 waterproofing, and -10℃–40℃ operating range ensure all-weather reliability.
Long-Lasting Components: Same LED, battery, and solar panel lifespans as the other two series.
Versatile Features: Remote control, customizable radar sensor, and multi-mounting options (pole/roof/wall).
3.3 Perfect Use Cases
Highways, large parks, industrial campuses, and expansive scenic areas—ideal for lighting vast spaces with consistent brightness.
4. Shared Advantages Across All Series
All-In-One Design: Integrates solar panel, battery, LED, and controller into one unit, reducing installation complexity and maintenance costs.
Eco-Conscious Operation: Relies on solar energy, cutting grid electricity use and lowering carbon emissions.
Universal Compatibility: 60mm pole mounting caliber and multi-installation options fit diverse outdoor setups.
Quality Assurance: 2-year warranty provides peace of mind for long-term use.
